As an important industrial handling equipment, Vote forklift is widely used in cargo yards, airports, stations, ports, warehouses, factory workshops, distribution centers and distribution centers. It can enter the cabins, carriages and containers to load and unload and carry pallet cargo.
our Advantages
Product Details
Accessories
Product Parameters
Characteristic
Rated capacity
3500 kg
Lift height
3000 mm
Load center distance
500 mm
Power mode
Lead-acid battery
Wheelbase
1850 mm
Fork size(L*W*T)
45*122*1070 mm
Configuration
Truck body size (fork excluded)
2680*1225*2200 mm
Battery voltage / nominal capacity
72V/260Ah
Battery weight
430 kg
Tyre(front/rear)
28*9-15 / 18*7-8
Front overhang
467 mm
Service brake / parking brake
Hydraulic / Mechanial
Ground clearance at center of wheelbase(laden)
145 mm
Performance
Travel speed(Laden/unladen)
10 km/h
Lifting speed(Laden/unladen)
200/300 mm/s
Lowering speed(Laden/unladen)
450 mm/s
Max.climbing angle
12/20 %
Ground clearance under mast
82 mm
Turning radius
2300 mm
